2250 Knock Out
25,000 FT.- LB. Moment Rating and 5,000 Lb. Max Capacity.
● Power elevation from -5 degrees to + 75 degrees.
● Continuous & Unlimited power rotation.
● Rotates on a gear bearing driven by a worm gear box with a 45:1 ratio.
● The 2550X-20 has power boom extension from 10ft to16ft. with a manual pull out to 20ft
● The 2550XP 12-20 has power boom extension from 12ft to 20ft. and comes standard with
wireless proportional controls.
● Both load sensor & anti two-block are standard.
● All cylinders have a integral counterbalance valve for safety, this valve holds
the load in the event of hose failure and controls the rate of boom decent.
● 80 ft. of 5/16" galvanized aircraft cable with 9,800 lbs. breaking strength.
● Optional wireless controls available for the 2550X with the on/off control system.
Recognized as a quality leader in commercial vehicle upfits.
