25,000 FT.- LB. Moment Rating and 5,000 Lb. Max Capacity.
● Power elevation from -5 degrees to + 75 degrees.
● Unlimited power rotation.
● Rotates on Gear Bearing slewing ring.
● Two standard models are available
5000WX-20 power extension from 10ft.-16ft. with a manual pull out to 20ft.
5000WX 12-20 power extension from 12ft. - 20ft.
● Planetary gear driven winch with 2.5 Hp series wound motor
● 80ft. of 5/16" galvanized aircraft cable, 9,600lbs breaking strength
● All cylinders incorporate an integrally mounted counterbalance valve for safety.
● Pressure switch and anti two-block are standard features.
● Optional wireless radio controls are available.
(wireless controls maintain the use of the standard wired pendant )
