Item #5000W



25,000 FT.- LB. Moment Rating  and  5,000 Lb. Max Capacity.

● Power elevation from -5 degrees to + 75 degrees.

● Unlimited power rotation.

● Rotates on Gear Bearing slewing ring.

● Two standard models are  available

    5000WX-20 power extension from 10ft.-16ft. with a manual pull out to 20ft.

    5000WX 12-20 power extension from 12ft. - 20ft.

● Planetary gear driven winch with 2.5 Hp series wound motor

● 80ft. of 5/16" galvanized aircraft cable, 9,600lbs breaking strength

● All cylinders incorporate an integrally mounted counterbalance valve for safety.

● Pressure switch and anti two-block are standard features.

● Optional wireless radio controls are available.

   (wireless controls maintain the use of the standard wired pendant )
