Item #6036WX


36,000 FT.- LB. Moment Rating and 6,000 Lb. Max Capacity.


● Power extension from 10ft.-16ft. with a manual pull out to 20ft.

● Power rotation is unlimited.

● Rotates on Gear Bearing Slewing Ring.

● Power elevation from -5 degrees to + 75 degrees.

● Anti two-block and pressure switch are standard.

● Planetary gear driven winch with 2.5 Hp series wound motor

● 90 ft. of 5/16 6 X 36 Wire Rope with 10,540 Breaking strength.

● All cylinders incorporate an integrally mounted counterbalance valve for safety.

● Optional wireless radio controls are available.

  (wireless controls maintain the use of standard wired pendant)
